Placa Base Asus Strix X870e-H Gaming Am5 Atx Wifi7 Am5 Ddr5 Atx 90mb1m90-M0eay0

ASUS ROG STRIX X870E-H GAMING WIFI7

ASUS ROG STRIX X870E-H GAMING WIFI7, Windows 11, Realtek ALC1220P 7.1 Surround Sound
High Definition Audio CODEC*
-..., Supports 4 x M.2 slots and 4 x SATA 6Gb/s
ports
AMD Ryzen™ 9000 & 7000 Series..., 4 x DIMM slots, max. 256GB, DDR5
Supports up to 8000+MT/s(OC) with Ryzen™
9000 & 8000..., 1 x HDMI™ port**
2 x USB4^® (40Gbps) ports support USB
Type-C^®...

Características

• Sistema operativo Windows soportado: Windows 11

Otras características

• Salida de audio: Realtek ALC1220P 7.1 Surround Sound
  High Definition Audio CODEC*
  - Impedance sense for front and rear
  headphone outputs
  - Internal audio Amplifier to enhance the
  highest quality sound for headphone and speakers
  - Supports: Jack-detection,
  Multi-streaming, Front Panel Jack-retasking
  - High quality 120 dB SNR stereo playback
  output and 113 dB SNR recording input (Line-in)
  - Supports up to 32-Bit/192 kHz
  playback*
  Audio Features
  - SupremeFX Shielding Technology
  - Savitech SV3H712 AMP
  - Rear optical S/PDIF out port
  - Premium audio capacitors
  - Audio cover
  * The LINE OUT port on the rear panel does
  not support spatial audio. If you wish to use spatial audio, make sure to
  connect your audio output device to the audio jack on the front panel of your
  chassis or use a USB interface audio device.
• Características especiales: Supports 4 x M.2 slots and 4 x SATA 6Gb/s
  ports
  AMD Ryzen™ 9000 & 7000 Series Desktop
  Processors
  M.2_1 slot (Key M), type 2242/2260/2280
  (supports PCIe 5.0 x4 mode)
  M.2_2 slot (Key M), type 2280/22110
  (supports PCIe 5.0 x4 mode)*
  AMD Ryzen™ 8000 Series Desktop Processors*
  M.2_1 slot (Key M), type 2242/2260/2280
  (supports PCIe 4.0 x4/x2 mode)
  M.2_2 slot (Key M), type 2280/22110 (Not
  supports)**
  AMD X870E Chipset
  M.2_3 slot (Key M), type 2280 (supports
  PCIe 4.0 x4 mode)
  M.2_4 slot (Key M), type 2280 (supports
  PCIe 4.0 x4 mode)
  4 x SATA 6Gb/s ports
  * M.2_2 shares bandwidth with PCIEX16(G5).
  When M.2_2 is occupied with SSD device, PCIEX16(G5) will run x8 only.
  ** M.2_2 will be disabled when using AMD
  Ryzen™ 8000 Series Desktop Processors.
• Otras características: 4 x DIMM slots, max. 256GB, DDR5
  Supports up to 8000+MT/s(OC) with Ryzen™
  9000 & 8000 & 7000 Series Processors
  Dual channel memory architecture
  Supports AMD Extended Profiles for
  Overclocking (EXPO™)
  Supports DIMM Fit / DIMM Fit Pro
  ASUS Enhanced Memory Profile (AEMP)
  * Supported memory types, data rate
  (speed), and number of DRAM modules vary depending on the CPU and memory
  configuration, for more information please refer to CPU/Memory Support list
  under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
  Adjustments will be made based on the specifications of mass-produced memory
  products available on the market.
  ** Non-ECC, un-buffered DDR5 memory
  supports On-Die ECC function.
• Producción gráfica: 1 x HDMI™ port**
  2 x USB4^® (40Gbps) ports support USB
  Type-C^® display outputs***
  * Graphics specifications may vary between
  CPU types. Please refer to AMD CPU specifications.
  ** Supports 4K@60Hz as specified in HDMI
  2.1.
  *** Supports max. 4K@60Hz as specified in
  DisplayPort 1.4a
  **** VGA resolution support depends on
  processors' or graphic cards' resolution.

Descargar ficha técnica (PDF)
